- USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH AUTOMATIC A/B-AXIS HEAD
SACHMAN - FRAZER
- USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH AUTOMATIC A/B-AXIS HEAD
SACHMAN - FRAZER
- USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH AUTOMATIC A/B-AXIS HEAD
| YEAR | 2017 |
| CODE | 24U8941 |
| LONGITUDINAL TRAVEL | 3000 mm |
| TRANSVERSAL TRAVEL | 1100 mm |
| VERTICAL TRAVEL | 1500 mm |
| RAPID FEEDS L-T-V | 35 m/min |
| TABLE SIZE | 3100 x 1000 mm |
| HEAD | IN CONTINUO ; ISO 50 ; 8000 rpm; 25/33 kW; 480/640 Nm |
| TOOL MAGAZINE | CHAIN-TYPE ; 24 POS |
| CONTROL UNIT | HEIDENHAIN TNC 640 |
| HIGH PRESSURE COOLANT | 15 Bar |
| WEIGHT | 30500 Kg |
| ACCESSORIES | SWARF CONVEYOR ; ETHERNET PORT ; PORTABLE HANDWHEEL ; LINEAR SCALES ; THROUGH-SPINDLE AIR BLAST |
| NOTE | LASER TOOL SETTER BLUM; TOUCH PROBE RENISHAW RMP-60; EXTERNAL SPINDLE SPRAY MIST LUBRIFICATION; GUARD FOR PENDULUM MACHINING |
| PRICE |
0
To be defined
EUR
InStock
|
Video Company
All the mentioned technical data are merely intended to describe the item, they are subject to change without any notice and refer to the standard conditions of a new good. A used good might not have the same figures as the new one.
