- USED - 3-AXIS VERTICAL MACHINING CENTRE
MISSION 5
- USED - 3-AXIS VERTICAL MACHINING CENTRE
MISSION 5
- USED - 3-AXIS VERTICAL MACHINING CENTRE
| YEAR | 2001 |
| CODE | 19U6540 |
| X-AXIS TRAVEL | 1250 mm |
| Y-AXIS TRAVEL | 600 mm |
| Z-AXIS TRAVEL | 685 mm |
| DISTANCE SPINDLE NOSE-TABLE | 150 - 835 mm |
| DISTANCE COLUMN-SPINDLE AXIS | 650 mm |
| SPINDLE | 40-12000 rpm; 18,5-25 kW; ISO 40 - DIN |
| TABLE SIZE | 650 x 1400 mm |
| MAX ADMITTED LOAD | 1400 Kg |
| TOOL MAGAZINE | CHAIN-TYPE ; 21 POS |
| MAX TOOL DIAMETER | 75 (100) mm |
| MAX TOOL LENGHT | 250 mm |
| MAX TOOL WEIGHT | 6 Kg |
| CONTROL UNIT | FANUC 18i-M |
| WEIGHT | 8000 Kg |
| OVERALL DIMENSIONS | 2860 x 3580 x 3045 mm |
| ACCESSORIES | HIGH PRESSURE COOLANT ; SWARF CONVEYOR |
| PRICE |
0
To be defined
EUR
SoldOut
|
Video Company
All the mentioned technical data are merely intended to describe the item, they are subject to change without any notice and refer to the standard conditions of a new good. A used good might not have the same figures as the new one.
